ProE Plastic Extrusion Mold 2316 Steel Channel Din 1.2316 Extrusion Injection Moulding

Place of Origin China
Brand Name Gennki
Certification ISO9001 / TS 16949
Minimum Order Quantity 1 mold
Price discuss base on certain RFQ
Packaging Details plastic film wrapped or vacuumed, and sustained in the wooden crate
Delivery Time 35 days
Payment Terms T/T
Product Details
Shaping Mode Extrusion Mould Application Construction Industry
Mold Steel 2316 Surface Treatment Mirror Polishing
Design Software ProE Plastic Material PVC, PP, PE
Compatible Format Iges, Prt, Step Incoterm FOB
High Light

ProE Plastic Extrusion Mold


2316 steel Channel Plastic Extrusion Mold


Din 1.2316 extrusion injection moulding

Leave a Message
Product Description

Material: Polyethylene (PE, HDPE, LDPE, PET) Polyvinyl Chloride (PVC)

AT GENNKI, We are well aware that oftentimes our products are sub-assemblies or require additional work before they arrive at your facility. We can review your requirements and determine the best path forward to deliver the product you are needing.

Machining, With an in-house tooling and machine shop, we can machine your parts after they have been extruded to get the desired results.

Assembly, Do you need assistance with some of the assembly for your part? We are happy to offer this service.

Protective Coatings, Do your parts require a special application or protective application? We can incorporate the application as part of the manufacturing process.


Product Name
PVC Extrusion Profile Mould/Plastic Profile Die/UPVC Profile Mould and Extrusion Line
Mould Material
3Cr13, 3Cr17, 3Cr17NiMoV mould steel or Din 1.2316
Die head + calibrator + water tank
Custom made
Die Strand
One or two
Testing Sample
Testing samples can be offered upon customers' request
Lead Time
35 working days
Delivery Port
Mould Packing
Plywood cases
One set


ProE Plastic Extrusion Mold 2316 Steel Channel Din 1.2316 Extrusion Injection Moulding 0ProE Plastic Extrusion Mold 2316 Steel Channel Din 1.2316 Extrusion Injection Moulding 1ProE Plastic Extrusion Mold 2316 Steel Channel Din 1.2316 Extrusion Injection Moulding 2


Frequently Asked Question:

Q1. What is required of RFQ?
1) 3D formats with .stp.(preferred) igs,.prt.
2) 2D drawing for tolerance/material/surface finish/test requirement/regulations
3) Quantity (by order, month and Year)
Q2. How do you ensure product quality?
Gennki applies assessment, planning, monitors every single process. Some bullet points:
1) Apply APQP Product development analysis
2) Lay emphasis on prevention and planning
3) Quality Criteria (ISO and TS 16949)
Q3. How do you ensure on-time delivery?
1) Detailed planning, details per hour/person/machine number/stakeholder…
2) Main material is managed efficiently
3) Daily progress meetings, a recovery plan will be reviewed by the management team once any key chain is a delayed.
4) If a delay happens on delivery in the course, extra hours will help to turn it on schedule
Q4. How can you if we don’t have the CAD data?
Gennki is able to generate the CAD for your review and approval in terms of your 2D sketch, or certain samples.
Q5. Can we test the plastic injection mold?
You are always welcome to the company with us to try the molds in place in person. The testing video can be supplied for your checking with your absence.
Q6. How long does an injection mold last?
Generally, a plastic injection mold could complete anywhere between 100,00 to 1 million (or sometimes somewhat more than a million) cycles in its lifetime, so it's subject to customer’s expectancy.
Q7. How about your guarantee or aftersales?
The worn-easily spare parts will be freely provided during the warranty period. Gennki’s strategic associated American mold shop will assist you to handle the modification change if needed after the delivery.
Q8. How Can I visit your company from abroad?
Easy to find, you may take an international flight either land at PVG Airport or Hongqiao Airport from your workplace. The nearby high-speed train station to Hongqiao Airport will facilitate your trip to elsewhere in China.
