P20 H-13 Plastic Moulding Dies UG PVC Injection Molding Rapid Prototype Making

Place of Origin China
Brand Name Gennki
Certification ISO9001 / TS 16949
Minimum Order Quantity 1 mold
Price discuss base on certain RFQ
Packaging Details protective film wrapped, and packed in carton or plywood case
Delivery Time 45 days~60 days
Payment Terms T/T
Supply Ability 60 sets/Monthly
Product Details
Process Injection Molding Plastic Material Various Kinds Of Injection Material
Steel P20 Or H-13 Design Software Solidworks, Proe, Catia, UG
Design Format IGES, Prt. Step Hot Tip Incoe, Yudo, Moldmaster
Standard DME And Hasco Incoterm FOB
Export US
High Light

P20 plastic moulding dies


H-13 plastic moulding dies


UG pvc injection molding

Leave a Message
Product Description

China East OEM injection molding service and custom mold making



With Gennki Group, the manufacturing service of rapid prototype making, injection molding service, aluminum die casting service, stamping, assembly.

With reference to mold manufacturing, the following sequence may make sense.

Step 1 --Loading in a Part Model

  • Load in the product model,
  • assign the mold pull direction and scale factor,
  • Create the containing box

Step 2 --Creating the Layout, Gates, and Runners,

  • Define the cavitation of the mold
  • Create gating for the part mode,
  • Create the runners between the gate

Step 3 --Loading in a Mold Base

  • define the style of the mold base
  • select the series of moldbase
  • enter the size any necessary customized specification of mold base

Step 4 --Creating the parting line and inserts

  • define the parting line for the creation of core and cavity
  • create necessary inserts

Step 5 --Designing the Hot Runner System (Optional)

  • define the style of manifold,
  • design the nozzle and runner system

Step 6 --Designing the Sliders, Lifters

  • Using the slider design will create the lifter head and lifter body that are required in the design for interior undercuts.

Step 7 --Designing the Cooling system

  • define the cooling channels for the core, cavity, plates, slides, or lifters
  • add standard cooling accessories to the cooling system.

Step 8 --Designing the Part Ejection system

  • define the ejector pins needed to eject the part from mold
  • choose the different styles and sizes of ejector pins that are needed in the design

Step 9 --Adding in Standard Parts

  • define and locate standard parts like the socket head cap screw and location locating rings to complete the mold desigh


Step 10 --Design of Electrodes for CAM

  • define the boundaries of geometry for electrodes
  • select an electrode tool holder for electrode designed
Product Description
Make injection molds and produce plastic injection molding parts
Plastic Materials: PS, ABS, PP, PVC, PMMA, PBT, PC, POM, PA66, PA6, PBT+GF, PC/ABS, PEEK, HDPE, TPU, PET, PPO,...etc.
Other materials: Rubber, Slilcone rubber, LSR, Aluminum, Zinc, Copper...Metal...etc.
Quality: RoSH and SGS standard
Feature: Non marking and Non flash
Size: According to your 2D or 3D Drawing
Color,Quantity,Unit price,Tooling cost,Tooling size: To be discussed
Package: Standard exported Wooden box packed, Fumigation process(upon required)
Mold Building Lead Time: T1, 4-5 weeks, Part measurement report (upon required).
Export Country: Europe, America, Australia, UK, Canada, France, Germany, Italy, Japan...etc.:
To be discussed In-Mold Decoration, Injection Mould, Plastic Mold, Overmould, 2K Mould, Die-Casting Mould, Thermoset Mold, Stack Mold,
Interchangeable Mold, Collapsible Core Mold, Die Sets, Compression Mold, Cold Runner System LSR Mold,...etc.
Mould Base: Hasco Standard, European Standard, World Standard
Mould Base Material: LKM, FUTA, HASCO, DME,...etc. Or as per the Customer's requirement.
Surface Finish: Texture(MT standard), High gloss polishing
Cavity/Core Steel: P20, 2311, H13, 2344, Starvax 420, 236, AdC3, S136, 2312, 2379, 2316, 2083, Nak80, 2767 ...etc.
Hot/ Cold Runner HUSKY, INCOE, YDDO, HASCO, DME, MoldMaster, Masterflow, Mastip
Mould Life: 5,000 to 1,000,000 Shots. (According to your working environment.)
Design & Program Softwares: CAD, CAM, CAE, Pro-E, UG, Solidworks, Moldflow, CATIA....etc.
High-speed CNC, Standard CNC, EDM, Wire Cutting, WEDM, Grinder, Plastic Injection Molding Machine for trial out mold from 50-3000T


P20  H-13 Plastic Moulding Dies UG PVC Injection Molding Rapid Prototype Making 0P20  H-13 Plastic Moulding Dies UG PVC Injection Molding Rapid Prototype Making 1P20  H-13 Plastic Moulding Dies UG PVC Injection Molding Rapid Prototype Making 2
